Pinch Valve meant for Electric Actuator, 33a921r, P98044





DN

D

D 1

L

d

h1

n

Weight,
no more, kg

50

50

160

230

18

25

4

6

80

80

195

310

18

40

4

9




Direction of working medium - any.
Full tight shut - off.

The design of the valve provides for positive opening of the sleeve.
Nominal pressure, PN - 0,6 M–a. (6 kgf/cm2)
Working medium: liquid medium for water supply and sewerage systems, not aggressive and aggressive, pulps, liquid and viscous media,
mineral oils and petroleum products.
Version - normal, export, tropical.
Body material - aluminium.
At diferent valve's position must be instolled additional supporting pier for electric actuator.
Normal, Explosionproof types of electric actuator available.
Connection - flanges.

Valve working position - any with additional supporting pier for actuator, exept position with actuator down.
